Product Advantages：Parameters such as pulse waveforms, heart rate values, blood oxygen levels, vascular microcirculation and reference blood pressure can be directly output.
Integrated red and infrared light LEDs can be used for blood oxygen measurement.
Broad-spectrum high-sensitivity optical sensor
An ultra-small size of 30.04mm x 11.04mm x 7.8mm
Ultra-low operating power consumption
Easy-to-use UART interface output
Connecting to the cloud-based analysis platform also enables the acquisition of additional cardiovascular health indicators such as heart rate variability (HRV), arrhythmia, heart rate scatter plots (for risk assessment of atrial fibrillation, premature beats, etc.), and respiratory rate.
Key features:
1. It can directly output pulse waveforms, heart rate values, blood oxygen levels, and vascular microcirculation parameters.
The JFS-5V45-HRV is a multi-spectral physiological data measurement module developed by Jingfan Technology. It has an independent algorithm for data analysis and can accurately measure pulse waveforms, heart rate values, blood oxygen levels, and vascular microcirculation parameters, etc.
2. Patented sensors
The patented front-end sensor technology has significantly improved the sensitivity and signal-to-noise ratio of the module compared to similar products.
3. An ultra-small size of 30.0mm * 11.0mm * 7.8mm
The JFS-5V45-HRV module also has the characteristics of an ultra-small size and ultra-low power consumption, which enhances the battery life of smart wearable devices and the flexibility of the appearance design.
4. A one-stop data management and analysis platform
The cloud-based large database platform processes and analyzes pulse wave data to obtain analysis reports on long-term heart rate, blood oxygen, and microcirculation, as well as reports on blood pressure, respiratory rate, heart rate variability, and other diseases. Various analysis services are continuously upgraded.
Product Specifications:
Model: JFS-5V45-HRV Integrated Module
Length: 30.0mm
Width: 11.0mm
Operating Voltage: 4.8 - 5.2V
Operating Current: 5mA
Sleeping Current: 3.4uA
Output Data: Heart rate, blood oxygen, microcirculation, etc.
Application Scenarios: Massage chairs, smart home devices, etc.
